The small and powerful Dayton Audio DTA-120 Class T amplifier installs virtually anywhere.
It produces big-amp sound while occupying minimal space on your desk or A/V cabinet.

Everything You Need in a Mini Amp

Dayton Audio has revamped the popular DTA-100 mini amplifier with an all-new design that improves on every part of the DTA-100's performance. The result is the Dayton Audio DTA-120 Class T digital amplifier. It's everything you need in a mini amp, delivering the performance of enormous hi-fi gear, and smart features you'll wonder how you lived without... and thanks to the space-saving design, it fits and installs practically anywhere!

Big-Amplifier Power

The DTA-120 amplifier delivers the power of a monster amplifier, but in a tiny package. Thanks to Tripath's proprietary Class T technology, plus a robust Dual Parallel BTL configuration, the DTA-120 tackles the toughest speaker loads with ease -- while delivering the sound quality and low distortion of a conventional Class AB amplifier. The dual-power-chip design delivers 60 watts (RMS) per channel of efficient power into an 4 ohm load (up to 120 watts total), and 40 watts (RMS) into 8 ohms - continuously, with no reduction in output. That means powerful bass and clear output that keeps on going, even with the most demanding speakers.

Convenient, Small Size

With the DTA-120 amplifier, you get the most power possible from the smallest footprint imaginable. At under 3-1/2" wide, 2-1/4" tall, and 6" deep, the DTA-120 delivers more power per cubic inch than any other mini amplifier. All this is thanks to the revolutionary, cool-running Class T digital PWM amplifier technology and the extruded aluminum heatsink case. The robust external switching power supply hides out of sight. But since it can supply high current with even higher peaks, the DTA-120 can easily drive HUGE speakers.

High-End Features and Quality

The DTA-120 amplifier delivers the features you expect in a much more expensive amplifier, at a fraction of the size and price. The housing is black-anodized aluminum, with a thick machined faceplate and a silky-smooth volume control. The rear panel features high-quality, gold-plated RCA inputs and shielded, gold-plated 5-way binding posts that accept any type of speaker cable. A high-current DC power jack is also used to ensure maximum power transfer to the amp. On the front panel, there's a second 3.5 mm audio input jack, as well as a 1/4" headphone jack that receives its signal from a separate, high-quality headphone amplifier stage controlled by the main volume knob. (3.5 mm to 1/4" adapter included.)

Works With ALL Your Sources

In a world of changing digital and wireless specifications, the high-quality analog design of the DTA-120 remains virtually future-proof. Just connect it to any device with a headphone output jack and begin enjoying powerful, high-quality audio through your own speakers. Short signal paths inside the amplifier preserve all the quality of the input signal, and the DTA-120 automatically switches from the rear inputs to the front input when connected. No switches to flip, and just one knob. The DTA-120 is the perfect complement to your smartphone, tablet, laptop, PC, television, or any other audio source.

Head-Fi Friendly Design

The DTA-120 is the ultimate desktop amplifier. Not only can it drive even the smallest and least-efficient speakers to almost painful levels without strain, making it perfect for powering desktop mini-monitor speakers, but it also offers a separate solid-state headphone amplifier stage capable of powering even the most demanding headphones to high listening levels while preserving clarity, detail, and a refined sonic character. However you like to listen at your desk, the DTA-120 is the perfect partner.

accesorii boxe	filtre boxe	difuzoare
boxe/kit-uri/căşti	stand/rack	cabluri
amplificatoare	LP/CD/DAC	unelte

	Dayton Audio DTA-120 Integrated Amplifier

	The small and powerful Dayton Audio DTA-120 Class T amplifier installs virtually anywhere. It produces big-amp sound while occupying minimal space on your desk or A/V cabinet. Everything You Need in a Mini Amp Dayton Audio has revamped the popular DTA-100 mini amplifier with an all-new design that improves on every part of the DTA-100's performance. The result is the Dayton Audio DTA-120 Class T digital amplifier. It's everything you need in a mini amp, delivering the performance of enormous hi-fi gear, and smart features you'll wonder how you lived without... and thanks to the space-saving design, it fits and installs practically anywhere! Big-Amplifier Power The DTA-120 amplifier delivers the power of a monster amplifier, but in a tiny package. Thanks to Tripath's proprietary Class T technology, plus a robust Dual Parallel BTL configuration, the DTA-120 tackles the toughest speaker loads with ease -- while delivering the sound quality and low distortion of a conventional Class AB amplifier. The dual-power-chip design delivers 60 watts (RMS) per channel of efficient power into an 4 ohm load (up to 120 watts total), and 40 watts (RMS) into 8 ohms - continuously, with no reduction in output. That means powerful bass and clear output that keeps on going, even with the most demanding speakers. Convenient, Small Size With the DTA-120 amplifier, you get the most power possible from the smallest footprint imaginable. At under 3-1/2" wide, 2-1/4" tall, and 6" deep, the DTA-120 delivers more power per cubic inch than any other mini amplifier. All this is thanks to the revolutionary, cool-running Class T digital PWM amplifier technology and the extruded aluminum heatsink case. The robust external switching power supply hides out of sight. But since it can supply high current with even higher peaks, the DTA-120 can easily drive HUGE speakers.

	High-End Features and Quality The DTA-120 amplifier delivers the features you expect in a much more expensive amplifier, at a fraction of the size and price. The housing is black-anodized aluminum, with a thick machined faceplate and a silky-smooth volume control. The rear panel features high-quality, gold-plated RCA inputs and shielded, gold-plated 5-way binding posts that accept any type of speaker cable. A high-current DC power jack is also used to ensure maximum power transfer to the amp. On the front panel, there's a second 3.5 mm audio input jack, as well as a 1/4" headphone jack that receives its signal from a separate, high-quality headphone amplifier stage controlled by the main volume knob. (3.5 mm to 1/4" adapter included.) Works With ALL Your Sources In a world of changing digital and wireless specifications, the high-quality analog design of the DTA-120 remains virtually future-proof. Just connect it to any device with a headphone output jack and begin enjoying powerful, high-quality audio through your own speakers. Short signal paths inside the amplifier preserve all the quality of the input signal, and the DTA-120 automatically switches from the rear inputs to the front input when connected. No switches to flip, and just one knob. The DTA-120 is the perfect complement to your smartphone, tablet, laptop, PC, television, or any other audio source. Head-Fi Friendly Design The DTA-120 is the ultimate desktop amplifier. Not only can it drive even the smallest and least-efficient speakers to almost painful levels without strain, making it perfect for powering desktop mini-monitor speakers, but it also offers a separate solid-state headphone amplifier stage capable of powering even the most demanding headphones to high listening levels while preserving clarity, detail, and a refined sonic character. However you like to listen at your desk, the DTA-120 is the perfect partner.

	Specificaţii: Output power: 40W RMS x 2 @ 8 ohms, 60W RMS x 2 @ 4 ohms • Total harmonic distortion (THD): <0.1% @ 1W, <10% @ 60W • Frequency response: 20 - 20,000 Hz (+0/-1 dB at 8 ohms, +0/-3 dB at 4 ohms) • Signal-to-noise ratio: 103 dB, A weighted • Input sensitivity: 680 mV via rear input • Inputs: Rear stereo RCA, front 3.5 mm stereo mini-jack • Outputs: dual shielded, gold-plated mini binding posts (banana plugs accepted) • Power supply: Input: 100~240 VAC, 50/60 Hz, 1.6A; Output: 24 VDC, 4.75A continuous, with 2.5 mm DC plug • Power efficiency: >85% Dimensiuni: 86mm x 51mm x 159mm (including feet, faceplate, and volume knob). Greutate: 1,4kg Garanţie: 60 luni!
	Preţ: 140 €
